The Matek F405-HDTE is a flagship STM32F405 flight controller with integrated dual DJI HD VTX support, engineered for next-gen 3–7″ FPV freestyle and cinematic quads. Powered by a high-performance STM32F405RET6 MCU (168MHz, 1MB Flash) and paired with an ICM-42688-P IMU for ultra-low-noise gyro data, it delivers buttery-smooth flight characteristics with Betaflight, INAV, or ArduPilot firmware. The standout feature is two independent 5.8GHz DJI O3/Avatar HD digital VTX ports (plug-and-play via 6-pin connectors) plus a dedicated analog VTX pad set, enabling hybrid HD/analog setups or dual-camera switching. Onboard 12V/2A + 5V/2A BECs power the entire stack, while 8 motor outputs (4 dedicated + 4 shared) support X8 cinelifters or heavy 7″ X-class builds. Additional I/O includes 7 full UARTs, I2C, SPI, CAN, dual camera inputs, microSD card slot (Blackbox logging), and USB-C with OTG for fast tuning. Refined 30.5×30.5mm PCB with 3oz copper, ESD-protected pads, and vibration-damping mounts ensure rock-solid reliability under 6S–8S power. Pre-flashed with BF targets and DJI plug-and-play wiring. The ultimate all-in-one brain for HD digital domination.
